ZMN2405 Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
ADC Input Range
ADC Input Resolution
0
7
3.3
12
V
bits
ADC Input Impedance
PWM Output Resolution
55
12
M ?
bits
UART Baud Rate
1.2
115.2
kb/s
Digital I/O:
Logic Low Input Level
Logic High Input Level
-0.3
2.8
0.5
3.6
V
V
Logic Input Internal Pull-up/Pull-down Resistor
GPIO3 Logic Low Sink Current
20
20
K ?
mA
C
Power Supply Voltage Range
Power Supply Voltage Ripple
Receive Mode Current
Transmit Mode Current
Sleep Mode Current
Operating Temperature Range
V CC
+3.3
-40
27
28
+5.5
10
3
85
Vdc
mV P-P
mA
mA
μA
o
ZMN2405 Firmware Configurations
ZMN2405 modules are shipped loaded with one of three firmware configurations: coordinator, router or end
node. Each ZigBee network will include one, and only one coordinator. This module coordinates the overall net-
work operation and is the host application or gateway interface point for the network. The part number designation
for a coordinator is ZMN2405-C . Router modules are capable of retransmitting messages and provide the mesh
networking infrastructure in a ZigBee network. The part number designation for a router is ZMN2405-R . End node
modules provide field connection points for sensors, data loggers, PLCs, etc. The coordinator and the routers in a
ZigBee network must stay active (awake) continuously to support network operation. End nodes can be sleep
duty cycled where needed for extended battery life operation. The part number designation for an end node is
ZMN2405-E . A router can provide the same field connection support as an end node, but a router cannot be sleep
duty cycled without affecting mesh network operation. Specify the number of modules for each firmware configu-
ration when ordering ZMN2405 modules.
CAUTION: Electrostatic Sensitive Device. Observe precautions when handling.
www.RFM.com E-mail: info@rfm.com
?2008 by RF Monolithics, Inc.
Page 2 of 6
ZMN2405 - 5/20/08
